The H150S is a high-top, cast-in fire collar for concrete slabs 150mm and thicker
Approved for stack applications only.
For use with a range of pipe types and diameters (See below: click on a Report No. to access PDF)
Comes with a rubber ring that seals against the pipe.
Collar Approvals
BS ApprovalsEN Approvals
Pipe Material | Pipe Diameter Range | Pipe Wall Thickness range | Integrity | Insulation | Report |
---|---|---|---|---|---|
PVC, U-PVC, P-PVC & C-PVC Pipes | 110 to 160 | 3.2 to 4.0 | 240 | 240 | BRE P104650-1000 |
HDPE, MDPE & ABS Pipes | 125 to 160 | 5.0 to 15.0 | 240 | 120 | BRE P104650-1000 |
PP-R Pipes | 160 | 23.0 | 240 | 180 | BRE P104650-1000 |
Rehau Raupiano Plus | 160 | 4.2 | 240 | 240 | BRE P104650-1000 |
Valsir Triplus | 160 | 5.4 | 240 | 180 | BRE P104650-1000 |
Akatherm dBlue | 160 | 6.0 | 240 | 120 | BRE P104650-1000 |
Pipe Material | Pipe Diameter Range | Pipe Wall Thickness range | Integrity | Insulation | Report |
---|---|---|---|---|---|
PVC | 100 to 150 | 2.0 to 3.2 | 120 | 120 | BRE P104650-1003 |
PVC + Coupling | 100 to 150 | 6.6 to 9.5 | 120 | 180 | BRE P104650-1003 |
PP | 160 | 3.9 to 4.9 | 120 | 120 | BRE P104650-1003 |
PP + Coupling | 110 | 3.4 | 180 | 240 | BRE P104650-1003 |
PE-HD | 110 - 160 | 4.2 to 14.6 | 120 | 120 | BRE P104650-1003 |
Product Specs
Element Concrete slab
Cast-in or Retrofit Cast-in
Floorwaste or Stack Stack
Pipe Types HDPE, PP-R, PVC, Rehau Raupiano, Valsir Triplus, Akatherm dBlue
